BRACE Structural Steel 250UC-89-5 9000x250mm Diagonal

BRACE Structural Steel 250UC-89-5 9000x250mm Diagonal



For access to the Kit of Parts models, please Contact Us

Advanced Materials
Created By IGS BIM Solutions
Bulk Download Options
AreaXY
5.407 sqm
AreaXZ
90.457 sqm
HeightZ
4283 mm
LengthX
21120 mm
ModifiedIssue
V01.02
PerimeterXY
42752 mm
PerimeterXZ
50806 mm
Volume
23.157 cum
WidthY
256 mm
Types
